Traub TNC 65 DGY Lathe - CNC 65mm 1995

Specifications

Max. turning length: [mm] 450
Bar capacity: [mm] 65

Max. revolution: [rpm] 4.000
Input power: [kW] 18,5 / 11

Travel:
X-Axis: [mm] 140
Z-Axes: [mm] 450
C-Axis 2x
Rapid motion: (X/Z) [m/min] 15 / 30 / 6

Equipment:
Amount of turrets: 2
Turret 1 X Z Y
Y-Axis: [mm] 35
Turret 2 X Z
Tool capacity: 10
Driven Tools 10
Max. revolution: [rpm] 4.000
Tool: VDI 30

Subspindle
Max. revolution: [rpm] 5.600

Synchronized tapping
Tool setter
Partscatcher A left
Collets 2x Hainbuch-Spanntop BZI 65

Req. space (LxBxH): [m] 2,56 - 2,01 - 1,79
Machine weight: [kg] 4.550

Notes

Accessories:
Chip conveyor
Bar loader magazine Iemca
Toolholders 25x std. Halter, ang. Wz., Winkel, S"age Blatt
