Specifications

Specifications:
Chuck Size: 8"
Max Diameter Bar Capacity: 2.5"
Max Swing Over Bed / Carriage: 33.4" / 23.6"
Max Turning Diameter / Lower Turret: 21.6" / 11"
Distance Between Spindles: 50.4"
Max Machining Length: 40.1"
Main Spindle:
Spindle Motor: 30 / 20 HP
Spindle Speed: 4500 RPM
Spindle Bore: 2.99"
Spindle Nose: A2-6
Tools: 40 ATC
Rapid Traverse Rates (X & Z / Y): 945 / 630 IPM
Milling Motor: 25 / 20 /15 HP
Milling Speed: 8000 RPM
Sub-Spindle:
Sub Spindle Chuck Size: 6"
Sub Spindle Motor: 20 / 15 HP
Sub Spindle Speed: 6000 RPM
Sub Spindle Bar Capacity: 1.7"
Lower Turret Tools: 12
Lower Turret Milling Motor: 10 HP
Lower Turret Milling Speed: 4000 RPM
Tool Change Time (T - T): 1.6 Seconds
X-Axis Travel / Lower Turret: 22.2" / 6.1"
Z-Axis Travel / Lower Turret: 42.4" / 36.7"
Y-Axis Travel: +/- 3.1"
B-Axis Rotation: +/-120°
B-Axis Index: .0001 Degrees
C-Axis Index: .001 Degrees
Gear Ranges: 2
Max Tool Diameter: 3.5" / 4.9"
Max Tool Length: 11"
Max Tool Weight: 15.4 lbs.
Machine Dimensions (L x W x H): 254" x 126" x 138"
Machine Weight: 27,500 lbs.
