Sold!
Buy one like this

I want to sell a machine like this

  • CNC Machine
  • Mazak
  • INTEGREX 200 SY
  • Lathe - CNC
  • 1999
  • B Axis:
  • C Axis:
  • Y Axis:
  • Number of Axis: Yes
  • Live Tooling:
Mazak INTEGREX 200 SY Lathe - CNC 1999

Specifications

Max Swing over Bed..... 26"
Max Turning Diameter 26"
Max Spindle Speed......... 35 - 5,000 Rpm
Second Spindle Speed.. 35 - 5,000 Rpm
Live Spindle Speed 10,000 Rpm
Main & Second Spindle Nose........ a2-6
Main & Second Spindle Bore........ 2.99"
Spindle Indexing (Programmable)...... .0001 Deg
Second Spindle Indexing..... .001 Deg
Spindle Hp...... 30/20
Second Spindle Hp......... 25/20
Turret.... 20 Atc
Travels (X)..... 22.83"
(Z)...... 41.10"
(Y)..... +/- 3.15"
(B)..... .001 Deg
Rapid Travel Rate (X/Y/Z)....... 1023/1496/1496
Rapid Travel (B & C)....... 10-400 Rpm

Notes

Equipped With:
Mazatrol Fusion 640Mt Cnc Control
Main Spindle Rigid Tapping
Multi Tool Holer/Flash Tool Software
Eia/Iso Conversion Software
B Axis Angle Position Turning
Shape Compensation
High Speed Software
Gear Hobbing Software
Thread Start Compensation
Re-Thread
Polygon Machining
Tool Center Point Control
Simultaneous 5 Axis Control
Enhanced Y Axis Control
Auto Pecking
Sub Spindle C Axis Control
(2) 3 Jaw Chucks
Chip Conveyor
