Emco-Maier Hyperturn 690MC Lathe - CNC 4.2 2004

Specifications

Emco Model Hyperturn 690MC Plus, CNC Multi-Tasking Lathe, New 2004
Specifications:
Turning Dia 12" Nominal; 20.5" Max
Max Turning Length 42"
Max Swing 27.6"
Chuck Diameter 12"
Bar Capacity 3" Standard; 4.2" Maximum
Max. Speed 3000 RPM
Spindle Bore 4.2"
Drive Motor 72 HP
Type To Turret and Bottom Turret
Max Number of Tools
Turning 12 Top and Bottom
Rotary 12 Top and Bottom
Tool Shank Size
Square 1"
Round 1.6"
Rotary 1.6"
Travel: X-Axis 19.3"
Z-Axis 41.54"
C-Axis 360 Deg
Y-Axis 7.9"
Traverse Rate: X-Axis 1181 IPM
Z-Axis 1181 IPM
C-Axis 1000 IPM
Y-Axis 590 IPM
Floor Layout 194" L x 103" W x 103" H
Machine Weight 34,200 Lbs

Equipped With:
Siemens Control
Light
Foot Pedals
Bermec Chip Conveyor
All Available Tooling
Kelvin Chiller
Stand Coolant Thru Spindle ON Standard and Live Holders
(2) SMW AutoBlok No 4512 (Rear) No 4513 (Front)
315 BH 3-Jaw
Live Milling

Notes

Siemens Control
Light
Foot Pedals
Bermec Chip Conveyor
All Available Tooling
Kelvin Chiller
Stand Coolant Thru Spindle ON Standard and Live Holders
(2) SMW AutoBlok No 4512 (Rear) No 4513 (Front)
315 BH 3-Jaw
Live Milling
