  • CNC Swiss
  • Tsugami
  • BS19-III
  • Lathe - CNC
  • Swiss Type
  • 2005
  • Live Tooling:
Tsugami BS19-III Lathe - CNC Swiss Type 2005

Specifications

TSUGAMI BS19 MK-III
5-Axis Sub Spindle
CNC Swiss Lathe
w/ Fanuc 18i-TB Control
Chucking Dia. 3-19 mm
Max. Machining length 210 mm
Max. Drilling Dia. 7 mm
Max. Tapping 6 mm
Max. Cross drill M5 x .08
Main Spindle Speed 10,000 RPM
Main Spindle bore 23.5 mm
Spindle Index 15 Degree
O.D Tool Holders 7
Cross Driven Tool Holders 3
I.D. tool Holders 3
Backworking Tool Holders 3
Sub-Spindle Speed 8,000 RPM
Sub Spindle Bore 19.5 mm
Main Spindle Motor 1.1/3.7 Kw
Sub Spindle Motor 0.75/1.1 Kw
X1/Y/Z1/Z2 Axes Motor 0.3 Kw
A/B/X2/T3 Axes Motor 0.5 Kw
Voltage 220v

Notes

2005 Tsugami BS19B-III
with LNS Express 332 barloader. Machine
has approx 4-5000 hours with even less
cutting time. Only swiss in the shop so
everything goes with.
