Sold!Buy one like this
I want to sell a machine like this
- Automatic
- New Britain
- Model 52
- Multi Spindle Bar
- 6 Spindle
- 1965
Specifications
Maximum Capacity - Round 1-1/4"- Hexagon 1-1/16"
- Square 7/8"
Stock Feed - Maximum 5"
Tool Slide Travel 4"
Travel (Lower Slides) Front - Maximum 1-3/4"
Travel (Lower Slides) Rear - Maximum 2"
Lower Slides Feed - Maximum 1"
Middle Slides Travel - Maximum 1-3/4"
Middle Slides Feed - Maximum 1"
Travel (Upper Slides) Front - Maximum 1-3/4"
Travel (Upper Slides) Rear - Maximum 2"
Upper Slides Feed - Maximum 1"
Spindle Speeds 271 - 4249 RPM
Approximate Weight 12,900 Lbs.
Notes
(3) New Britain, Model 52, S/N 35228, 34613, 34346
Complete As Follows:
Stock Reel
Stock Stand
Pusher Tubes
Master Collets
Master Pushers
Cams As Mounted
Gears As Mounted
Plain Threading on 34346 and 34613
Universal Chip Conveyor
Aux. Pos. 4 on 35228
Aux. Pos. 5 and 6 for All Three
Two Circular Tool Holders on Each Machine
Drill Saddles
Mechanical Feed Clutches
Complete Guarding
Electrics - 440 Volt, 3 Ph, 60 Cyycle
Condition - Good, Just Taken out of Service
